에어피스톤 펌프

40 SEREIS

MODEL RS40-S RS40-D
Head Ttpe Single Double
Voltage DC12~24
Rated current 1.5A 2.5A
Free Flow Rate 12LPM 23LPM
Max. Pressure 7 bar 7 bar
Dimensions 180 x 80 x 80 180 x 80 x100
Noise 65 dB(A) ↓
Weight 1.15 kg 2.0 kg
Motor Type BLDC Type
Ambient Temp 0~40 ℃

70 SEREIS

MODEL RS70-S RS70-D
Head Ttpe Single Double
Voltage DC24
Rated current 10A 15A
Free Flow Rate 45 LPM 90 LPM
Max. Pressure 7 bar 7 bar
Dimensions 260 x 130 x 200 260 x 130 x 260
Noise 60 dB(A) ↓
Weight 6.5 kg 7.5 kg
BLDC Type BLDC Type
Ambient Temp 0~40 ℃
